GZ型電磁振動給料機 Elector-magnetic vibrating feeder
GZ系列電磁振動給料機廣泛應用于礦山、冶金、煤炭、建材、輕工、化工、電力、機械、糧食等各個行業，把塊狀、顆粒狀及粉狀物料從儲料倉或漏半中均勻連續或定量地給到受料裝置中。例如，向帶式輸送機、半式提升機、篩分設備等給料，向破碎機、粉碎機等喂料，以及用于自動配料、定量包裝等，并可用于自動控制的流程中，實現生產流程的自動化。
GZ elector-magnetic vibrating feeders are widely used in different industries such as mining, metallurgy, coal, building material, light industry, chemical, power, machinery and grain. They convey a given amount of block material, granule material and powdery material from the storage silo or hopper to the material receiving device in an even and uninterrupted way. For example, they feed materials through belt conveyors, bucket elevators or screening equipment to crushers or grinders. Besides, they are used for automatic charging, quantitative packaging, etc and even in the processes of automatic control to realize automation of production flow.
| 型號規格 Model | 槽子規格 | 給礦粒度 Feed size | 雙振幅 | 供電電壓 | 功率 Power | 給料量 t/h | 外形尺寸 Dimension | 重量 Weight | |||
| 長 | 寬 | 高 | 水平 | -10° | |||||||
| mm | mm | mm | mm | mm | V | kw | mm | t | |||
| GZ1 | 600 | 200 | 100 | 50 | 1.75 | 220 | 0.06 | 5 | 7 | 910×376×485 | 0.07 |
| GZ2 | 800 | 300 | 120 | 50 | 1.75 | 220 | 0.15 | 10 | 14 | 1175×506×600 | 0.15 |
| GZ3 | 900 | 400 | 150 | 75 | 1.75 | 220 | 0.2 | 25 | 35 | 1325×574×675 | 0.22 |
| GZ4 | 1100 | 500 | 200 | 100 | 1.75 | 220 | 0.45 | 50 | 70 | 1615×762×814 | 0.41 |
| GZ5 | 1200 | 700 | 250 | 150 | 1.75 | 220 | 0.65 | 100 | 140 | 1815×840×980 | 0.66 |
| GZ6 | 1600 | 900 | 250 | 200 | 1.5 | 380 | 1.5 | 150 | 210 | 2410×1092×1530 | 1.25 |
| GZ7 | 1800 | 1100 | 250 | 250 | 1.5 | 380 | 3.0 | 250 | 350 | 2800×1332×1710 | 1.9 |
| GZ8 | 2200 | 1300 | 300 | 300 | 1.5 | 380 | 4.0 | 400 | 560 | 3302×1556×1995 | 3.15 |
| GZ9 | 2400 | 1500 | 300 | 350 | 1.5 | 380 | 5.5 | 600 | 840 | 3515×1776×2200 | 3.75 |
| GZ10 | 2500 | 1800 | 375 | 500 | 1.5 | 380 | 4×2 | 750 | 1050 | 3630×2500×2235 | 6.5 |
| GZ11 | 2800 | 2000 | 375 | 500 | 1.5 | 380 | 5.5×2 | 1000 | 1400 | 4060×2640×2310 | 7.7 |
